Clipsal Max 4 Max4 Fork Teeth Comb Busbar 3P 1 - 4BB4/12/3
Fork comb busbar, MAX4, 3P, 80 A , 4 modules
1 In Stock
Need more?
This item is currently available for backorder with an estimated arrival time of 2 days
Please note this ETA is provided to us by our suppliers and could potentially be delayed due to factors outside our control. If there are any delays we will contact you to keep you updated.
Price
$58.62 $53.29
Choose your style, Select your Switch and Checkout
We can customise your powerpoint to a range of colours and layouts, suited to your needs.
Clipsal Max 4 Max4 Fork Teeth Comb Busbar 3P 1 - 4BB4/12/3
Width 270
Height 250
Depth 2170
| SKU | CLI4BB4/12/3 |
|---|---|
| Supplier No | 4BB4/12/3 |
| EAN / Barcode | 9311554636067 |
| Standards | AS/NZS 61009 |
| Width | 270 |
| Height | 250.000000 |
| Length | 2170.000000 |
| Width | 270.000000 |
| Brand | Clipsal |
| Range | Max4 |
| Number of Poles | 3 Pole + Neutral |
| Voltage | 380...415 V AC |
Max 4 Max4 Fork Teeth Comb Busbar 3P 1
Get Max 4 your buck
Complete protection with high performance. With Clipsal Max 4 you will find a range of enclosures, switchboards, residual current devices, miniature circuit breakers, isolators, distribution boards, overvoltage protection and accessories.
0 of 0 Reviews
A FEW FAQS
The kA rating for the busbar 4BB4/12/3 is - 20kA for 0.1s
No, unfortunately there isn't a 2 pole busbar that suits the RCBM combo. However you can use the 4BB4/12 but this only connects the active and the neutral still needs to be wired. For further information please visit https://updates.clipsal.com/ClipsalOnline/Files/Brochures/I0000126.pdf
The busbar to suit use to be 4BB4/12, however that part is no longer available. It has been replaced by the schneider model 21501. Description Ratings Rated operational current at 40°C (Ie) 80 A Rated conditional short-circuit current of an assembly (Isc) Compatible with the breaking capacity of Schneider E lectric circuit breakers Insulation voltage (U i) 440 V Rated voltage (U e) 230 V (P4 + N) - 400 V (3Ph + N) Rated impulse withstand voltage (U imp) 6 kV Degree of protection IP20 F ire resistance to IE C 69 5-2-1 Self-ext inguishing 9 60°C 30 s Colour RAL 7035 Number of 18 mm modules Comb busbar 1 12
