Schneider Evlink Pro Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable - EVA1RFKES

Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable
Dispatch. 2 days
Need more?
ITEM (1 qty)
BOX ( qty)
CARTON ( qty)
Price
$404.07 $367.34
Your order will have with items each
  • Same Day Dispatch
    Order before midday
  • 60-Day Returns
    stress-free purchasing
  • Full Supplier Warranty
    backed up product quality

Schneider Evlink Pro Enclosure, Metal, IP66, pedestal mount in metallic kit enclosure, for 25mm² to 35mm² cable - EVA1RFKES

Schneider Evlink Pro Enclosure
×
  • Schneider Evlink Pro Enclosure
  1. Schneider Evlink Pro Enclosure
Width 270
Height 360
Depth 180
Specification
SKUSCHEVA1RFKES
RangeEvlink
Width270.000000
Length180.000000
Height360.000000
BrandSchneider Electric
Supplier NoEVA1RFKES
IP RatingIP66
Number of Poles3 Pole + Neutral
Typeenclosure (type)
This EVlink Pro AC Metal accessory is an enclosure used to install protection devices inside the metallic enclosure. Depending on the protection chosen to be embedded into the EVlink Pro AC Metal enclosure, the installation of a Thalassa enclosure in the metallic kit may be necessary. The IP degree of protection is IP66. It can be used with single-phase or three-phase devices. The enclosure is equipped with 1 Telequick mounting plate, 2 DIN rails with a length of 240mm and 4 fixing brackets. The cables can enter via 2 M32 cable glands and 1 M12 one. The cable cross section id 25mm² up to 35mm². Its dimensions are (W) 270mm x (H) 360mm x (D) 180mm. Its product weight is 3.4kg. The IK degree of protection is IK09. The ambiant air temperature for operation is comprised between -30°C to 70°C.
